Product Introduction
The portable gas detector is a composite multi-gas detector suitable for industrial environments and environments prone to flammable, toxic, and harmful gases that pose risks to human health.
The gas detector, designed with advanced very large scale integrated circuit technology and in accordance with international standard intelligent technology levels, is a fully intelligent gas detector designed with a combination of digital and analog communication technologies. This intelligent gas detector is technologically advanced, performs exceptionally, is highly stable, and is convenient to use, greatly meeting the high reliability requirements for equipment in industrial site safety monitoring. The gas detector is widely used in industries such as petroleum, chemical, metallurgy, refining, gas distribution, biochemistry, and pharmaceuticals.
Video Show
Product features
Technical Specifications
| Measuring Gas | EX, O₂, CO, H₂S (customizable) |
| Basic Error | EX: ≤ ±5% FS; CO: ±10%; O₂: ±0.1% VOL; H₂S: ±10% |
| Response Time | EX: ≤ 30 s; CO: ≤ 30 s; H₂S: ≤ 30 s; O₂: ≤ 20 s |
| Indication Method | LCD display of real-time data and system status; LED, sound and vibration indication; alarm, fault and under-voltage indication |
| Working Environment | Temperature: -20°C to 50°C; Humidity: < 95% RH (non-condensing) |
| Operating Voltage | DC 3.7 V (lithium battery capacity: 2000 mAh) |
| Standby Time | ≥ 8 hours |
| Charging Time | 6–8 hours |
| Sensor Life | 2 years |
| Device Dimensions | 145 × 70 × 35 mm |
| Device Weight | ≈ 250 g |
