Product Introduction
Portable gas detection alarm devices are suitable for continuous monitoring of the concentration of toxic and harmful gases, as well as explosive gases in environments such as metal mines, coal mines, metallurgical smelting, petrochemical, municipal fire fighting, emergency rescue, tunnel operations, and gas and electric power industries.
When the gas concentration exceeds the limit, the device can automatically issue sound, light, vibration, and light bar alarms. It can be carried by relevant staff, managers, professionals, mobile workers, and coal mine ventilation and prevention personnel, and can also be used for fixed installation in the aforementioned locations.
The instrument's explosion-proof type is intrinsically safe and flame-proof for mining use, characterized by simple operation, convenient carrying, and high precision.
Product Features
Technical Specifications
| Technical Index | |
| Product name | DTS-B001(B) |
| Measuring method | Natural diffusion |
| Measuring gas | LEL、CH4、O2、CO、H2S、SO2、NO2、CL2、H2、NH3、CO2、PID |
| Display | Tft colorful lcd display |
| Alarm method | Sound, light, vibration alarm, alarm sound level 85db |
| Alarm point setting | Full range adjustable |
| Supply power | 1800mah rechargeable lithium battery |
| temperature/humidity | Temperature: -40℃~60℃ Humidity: ≤95%(no condensation) |
| Explosion-proof sign | Ex d ib I ii b t4 gb |
| Dimension/Weight | 107mm×55mm×30mm ≈150g |
| Standard configuration | Gas Detection Alarm*1, charger*1 (including a charging cable), calibration cover*1, instruction*1, |
Application Fields
Metal mines, coal mines, metallurgical smelting, petrochemical, municipal fire fighting, emergency rescue, tunnel operations, and gas and electric power industries.
