Product Introduction
This portable gas detection alarm (hereinafter referred to as the alarm) is a user-friendly personal protective device capable of continuous gas concentration monitoring. It employs internationally advanced gas sensors and features an OLED high-brightness LCD display that shows gas concentration levels, temperature, as well as primary and secondary audible, visual, and vibration alarms. The device is powered by a rechargeable polymer lithium battery.
Product Features
Adopting advanced imported sensors
It features three alarm modes: sound, light, and vibration.
OLED display can continuously and in real-time show gas concentration
Chinese menu mode
Real-time temperature display
Strong anti-electromagnetic and radio frequency interference
Power supply using rechargeable polymer lithium battery
The shell is made of high-strength, shock-resistant and drop-resistant materials.
IP68 ultra-high protection rating
Technical Specifications
| Product name | DTS-B001(S) |
| Measuring method | Natural diffusion |
| Measuring gas | LEL、CH4、O2、CO、H2S、SO2、NO2、CL2、H2、NH3、CO2、PID |
| Display | Tft colorful lcd display |
| Alarm method | Sound, light, vibration alarm, alarm sound level 85db |
| Alarm point setting | Full range adjustable |
| Supply power | 1800mah rechargeable lithium battery |
| temperature/humidity | Temperature: -40℃~60℃ Humidity: ≤95%(no condensation) |
| Explosion-proof sign | Ex d ib I ii b t4 gb |
| Dimension/Weight | 88mm×65mm×33mm ≈100g |
| Standard configuration | Gas Detection Alarm*1, charger*1 (including a charging cable), calibration cover*1, instruction*1 |
