Product Introduction
This product is a high-stability composite detector designed for detecting hazardous gases such as methane and carbon monoxide. The alarm uses advanced semiconductor methane sensors and electrochemical carbon monoxide sensors, featuring high stability and minimal sensitivity drift. Suitable for residential areas, villas, hotels, apartments and other places with flammable and harmful gases, it provides safety monitoring. It continuously monitors the concentration of methane and carbon monoxide, triggering an audible and visual alarm immediately when levels exceed limits to alert users.
Product Features
Semiconductor and electrochemical sensors with high stability
High sensitivity to gas
Microprocessor control
Sound and light alarm
Self-reset
Automatic fault detection indicator
SMT manufacturing process for good stability
Life monitoring function
Technical Specifications
| Product Model | DTS-S03 |
| Standard | GB 15322.2-2019 |
| Applicable Gas | Methane and carbon monoxide |
| Power Consumption | ≤ 3 W |
| Alarm Mode | Sound and light alarm |
| Input Voltage | AC 220 V, 50 Hz |
| Ambient Temperature | 0°C to 50°C |
| Relative Humidity | < 95% RH (non-condensing) |
| Alarm Concentration | Carbon monoxide: 150 ppm; methane: 10 %LEL |
| Dimensions | L90 × W90 × H38 mm |
| Service Life | 3 years |
