Product Introduction
The DTS-T000 gas pretreatment online monitoring system is an integrated sampling and detection solution for gases that cannot be measured directly by a standard detector, such as flue gas and exhaust gas containing moisture, oil and dust. A three-stage filtration device removes oil, dust and moisture from the sample, a vacuum sampling pump draws the gas through the system, and a built-in drainage pump automatically discharges condensate. A flow control device regulates the gas flow in real time, so the gas detector receives clean, stable sample gas and delivers rapid, reliable and stable detection.
The system monitors toxic and harmful gases and other industrial exhaust gases. It uses a waterproof design, and the gas analyzer can be integrated into the explosion-proof chassis or installed externally.
Technical Specifications
| Detection Principle | Catalytic combustion, electrochemical, infrared, PID, semiconductor |
| Detectable Gases | Toxic, flammable and explosive gases, oxygen, TVOC, etc. |
| Sampling Method | Pump suction (built-in sampling pump) |
| Measuring Range | 0–1000 ppm; 0–100 %LEL; 0–100 %VOL |
| Resolution | 0.01 / 0.1 / 1 |
| Accuracy | ≤ 5% FS |
| Adjustment Method | Keys and remote control (optional) |
| Response Time | Combustible gas: < 30 s; toxic gas: < 60 s |
| Recovery Time | Combustible gas: < 30 s; toxic gas: < 60 s |
| Ambient Temperature | -20°C to 55°C |
| Relative Humidity | ≤ 95% RH |
| Explosion-Proof Type | Flameproof |
| Power Supply | DC 24 V ± 12 V / AC 220 V |
| Output Signal | 4–20 mA, RS485 |
| Alarm Method | Audible and visual alarm |
Internal Structure of the Pre-treatment Online Monitoring System
Application
The DTS-T000 is suitable for gas sampling, purification and environmental emission monitoring of flue gas, exhaust gas, waste gas and other gases from combustion equipment, including boilers, heating furnaces, kilns (such as cement, glass and ceramic kilns), roasting furnaces, incinerators and coke ovens. It can also be used in high-temperature or low-temperature environments such as agricultural greenhouses, laboratories, cold storage facilities and high-temperature furnaces.
